WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded

WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
New
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
WANGLU IPC-9800ADHS-Plus CCTV IP&Analog Camera Tester Test 7-inch IPS Touch Screen Monitor CVBS Tester with HD-TVI/HD/CVI/AHD/SDI/POE/WIFI/8G TF Card/4K H.265/HDMI In & Out/RJ45 TDR/Firmware Upgraded
  • Stock: In Stock
$339.99
Ex Tax: $339.99


IPC-9800ADHS-Plus







Feature:

H.265/H.264, 4K video display via mainstream. 7 inch IPS touch screen, 1280*800 resolution.

5MP TVI(2560x1944P 12.5FPS) test, 4MP AHD(2560x1440P 15F/25F/30F) test, 4MP CVI(2560x1440P 25F/30F) test, 3G-SDI/HD-SDI/EX-SDI test(1080P 25/30/50/60fps) 4xzoom, video record and playback, Coaxial PTZ control and call camera OSD menu, 4K IP camera, dhcp server

RJ45 cable TDR test, cable quality test. Rapid ONVIF, auto view video, and create testing report.

Dual window test, IP &Analog camera test. TesterPlay, tester, android version mobile phone and PC display at the same time.

HDMI input & output, 1080p. Quick office(excel ,word ,PPT format ) doc. UTP cable tester. Customers self update software. Built in WIFI, create WIFI hotspot. IP discovery , shortcut button, drop-down menu. DC12V 2A, DC48V PoE power output.



Specification:

Model: IPC-9800ADHSPlus+

External power supply: DC 12V (2A)

Battery power supply: built-in 7.4V polymer lithium battery, capacity 5000mAh

Charging: Charging for 5-6 hours, one charge can be used normally for 10 hours

Operation settings: capacitive touch screen, Chinese, English OSD menu, optional

Automatic standby: off/5-30 minutes

Working temperature: -10℃---+50℃

Working humidity: 30%-90%

Dimensions: 240mm x 154mm x 46mm / 620g

Display screen: 7 inches, IPS high-definition full-view IPS capacitive touch screen, resolution 1920x1200

Network port: 10/100/1000M adaptive, RJ45

WIFI: Built-in wireless WIFI, rate 150M, receive wireless network camera images, etc.

H.265 main code stream test: hardware decoding, support H.265 main code test camera image, the highest resolution is 4K.

Dual display on one screen: Simultaneous testing of network and analog cameras.

IP camera test: ONVIF (with PTZ pan/tilt control), ACTi, Dahua IPC-HFW2100P, Hikvision DS-2CD864-E13, SMS SNZ-5200, Tiandi Weiye TD-NC9200S2, IPC120L, Honeywell HICC- 2300T, Aipu Wharton IP5000-BC-13MP/IRS06-13MP, Funitech IPC, Funitech kumkang8900, Fushijie BY-1080Q, WEISKY IPC and more than 80 brand cameras.

Lens Simulation: Simulate the "2.8/3.6/4/6/8/12/16/25mm" lens display area.

Focus information test: camera focus information, transmission signal quality, image quality test.

IP Discovery: Find the IP address of the camera on the entire network segment

Extremely fast ONVIF: Automatically log in to play images, activate Hikvision cameras with one key and modify parameters such as IP, generate test reports, etc.

Hikvision test tool: Hikvision camera one-key activation, image test, user name, password, IP and other parameters can be modified.

Dahua test tool: Dahua camera image test, supports batch activation of Dahua cameras, and can modify parameters such as user name, password and IP.

SDI2.0 video signal test: 1 channel HD-SDI/EX-SDI/3G-SDI IN BNC input, resolution support 720p 25/30/50/60fps,

1080p 25/30/50/60fps, 1080i 50/60fps, EX-SDI:2560*1440P 25/30FPS, 3840*2160P 25/30Fps

TVI 4.0 video signal test: 1 channel TVI IN BNC input, resolution support 720p 25/30/50/60fps, 1080p 25/30fps 2048x1536p 18/25/30fps , 2688x1520p 15fps , 2560x1440p 15/25/30fps, 2 592x1944P 12.5/20FPS / 3840 x 2160 12.5/15 FPS

CVI4.0 video signal test: 1 channel CVI IN BNC input, resolution support 720p 25/30/50/60fps, 1080p 25/30fps, 2560x1440p 25/30 fps/ 3840 x 2160 12.5/15 FPS

AHD4.0 video signal test: 1 channel AHD IN BNC input, the highest resolution supports 720p 25/30fps, 1080p 25/30fps, 2048x1536p 18/25/30fps, 2560x1440p 15/25/30fps, 2592x1944P 12.5/20FPS , 3840 x 2160 15FPS

CVBS video signal test: 1 channel Video IN BNC input, 1 channel Video OUT BNC output, support PAL/NTSC system

CVBS video signal level measurement: Measure the peak-to-peak value, sync level, and burst level of the video signal.

Video image enlargement: Support analog video image enlargement, IP network camera image enlargement and movement.

Video photography, video recording, photo browsing, video playback: Take screenshots and video recordings of the test screen, support Chinese naming and saving, photo browsing, and video playback operations.

Network cable TDR test: test network cable line pair status, length, attenuation, reflectivity, impedance, delay deviation and other parameters

HDMI input: one HDMI input, resolution support 720x480P/60fps720x576P/60fps, 1280x720P/25/30/50/60fps, 1920x1080P/25/30/50/60fps, 1920x1080I/50/60fps, 800x600P/60fps, 10 24x768P/60fps, 1280x1024P/60fps.

HDMI output: one HDMI output, resolution 1920*1080P.

PoE power output: 48V PoE power output, maximum power 25.5W.

DC 12V power output: output 12V with a maximum DC current of about 3A, providing temporary working power for the camera

USB 5V power output: 5V 2A power output function, can be used as a mobile phone charging treasure function.

Theme function: optional streamlined/ordinary user interface; custom function icons, desktop and application interface background, modify interface sliding effect.

Different display on the same screen: HDMI input small window can be opened, and the screen can display HDMI input signal and network camera and other signals at the same time.

Pull-down menu: PoE power switch, instrument IP setting, WLAN switch, HDMI input, color-barS output, LAN port traffic monitoring and other functions can quickly start the test.

Audio test: Input an audio signal to test whether the sound is normal, and it can be recorded and saved. One audio output for connecting headphones.

PTZ control test: Support RS485 bus, rate 600-115200bps. Support more than 30 protocols such as Pelco-D/P, SMS, Lilin, Yaan, etc.

Color image generator: Send PAL/NTSC multi-standard color-barS through the video OUT port.

UTP network cable test: Test any two or more network cables, and the connection order and network cable number will be displayed on the screen.

Protocol code capture: The built-in serial port tool can receive and display the RS485 protocol code data sent by the control device, and can also send hexadecimal code.

Network test function: IP address scan, link scan, PING packet test. Quickly find the IP address of an IP camera or other device connected to the meter.

PoE/PSE voltage test: Display the size of the power supply voltage and the connection of the line.



Package included:

1 x Camera Tester

1 x Tool Bag

1 x Power adapter

3 x Shoulder Strap

1 x TDR test cable

1 x Power output cable

1 x BNC video cable

1 x RS485 control cab

1 x Multimeter Test cable

1 x Network cable test box



Note:

Due to the different monitor and light effect, the actual color of the item might be slightly different from the color showed on the pictures. Thank you!

Please allow 1-2cm measuring deviation due to manual measurement.
